Xylem IM158 R04 Model SMVT User Manual
Page 11
SMVT Installation, Operation and Maintenance Manual
9
Maximum Working Pressure
Table 4: Maximum Working Pressure
Model
Maximum Pressure
175 psi
400 psi
SM1
up to (3) stages
more than (3) stages
SM2
up to (3) stages
more than (3) stages
SM3
up to (3) stages
more than (3) stages
SM4
up to (3) stages
more than (3) stages
SM5
up to (4) stages
more than (4) stages
SM6
up to (4) stages
more than (4) stages
Starts per hour:
Table 5: Electric Data
2
HP
Motor Frame
RPM
Voltage
Phase
Hz
Start/Hour
5
182TC 230 1
270
184TC
230/460
3
165
7.5
182TC 230 1
210
213TC
3
150
10
213TC
1 210
215TC
135
15
215TC
105
20
254TC
150
256TC
75
25
256TC
135
284TSC
3500
60
30
30
284TSC
230/460
60
286TSC
3
30
40
286TSC
45
324TSC
30
50
324TSC
45
326TSC
25
60
326TSC
30
364TSC
25
75
364TSC
2
365TSC
2
2
Electric data is based on Goulds Water Technology choice motors. Other manufacturer’s motors may have
different values.
