8 SMVT Installation, Operation and Maintenance Manual
III. Product Description
Description
This section provides a general description of the Goulds Water Technology Model SMVT
and key engineering specifications.
Overview
The Goulds Water Technology Model SMVT pumps are surface mounted, multi-stage,
vertical turbine pumps.
Pump impellers are closed, shaft driven, and held in position by a positive-locking taper
collet.
Suction and discharge connections are ANSI standard 3 inch 125# or 250# and 4 inch
125# or 250# flange type.
Pumps are available with standard ODP or TEFC motors.
Intended Use
Commercial Applications:
Booster Units
High Rise Building Water Applications
HVAC
Municipal Applications:
Package Pump Stations
Booster Stations
Water Treatment Applications
Irrigation Applications:
Turf Irrigation
Golf Courses
Stadiums
Greenhouses/ Nurseries
Sprinkler Systems
Engineering Data
Torque Values
Table 3: Torque Values
Description
Torque (ft.-lbs.)
Motor Bolts – 3, 5, 7.5 HP motors 20
Motor Bolts – 10 to 40 HP motors 45
Motor Bolts – 50, 60, 75 HP motors 70
Casing Bolts 120
Bowl Bolts 45
Coupling Bolts 28
Liquid Temperature:
Liquid temperature from -13ºF (-25ºC) to 150ºF (65ºC)
Note: Pump and piping should be protected from skin contact if temperature is less than
10ºC or higher than 40ºC
Product Description
