APPENDIX “A” ENGINEERING DATA
Pump Size
8x6x13
8x6x17M
8x6x17L
8x6x18
8x8x12
8x8x17 10x8x12S 10x8x12L 10x8x17S 10x8x17L
10x8x20S
K
CASING
DATA
(All Dimensions in Inches)
125# FF Std
Max. Suction Pressure
75
75
75
75
75
75
75
75
75
75
75
f ASA Flanges
Max. Working Pressure
175
175
175
175
175
175
175
175
175
175
175
h NOMINAL 175 PSI Max. Hydrostatic Test Pressure
262
262
262
262
262
262
262
262
262
262
262
Working Press.
Casing material
Cast I
Cast I
Cast I
Cast I
Cast I
Cast I
Cast I
Cast I
Cast I
Cast I
Cast I
g 250# FF
Max. Suction Pressure
200
200
200
200
200
200
200
200
200
200
200
c NOMINAL 280 PSI Max. Working Pressure
280
280
280
280
280
280
280
280
280
280
280
h Working Press.
Max. Hydrostatic Test Pressure
420
420
420
420
420
420
420
420
420
420
420
Casing material
Ductile I
Ductile I
Ductile I Ductile I Ductile I Ductile I
Ductile I
Ductile I
Ductile I
Ductile I
Ductile I
g 250# FF
Max. Suction Pressure
300
300
300
300
300
300
300
300
300
300
300
d NOMINAL 400 PSI Max. Working Pressure
400
400
400
400
400
400
400
400
400
400
400
e Working Press.
Max. Hydrostatic Test Pressure
600
600
600
600
600
600
600
600
600
600
600
h
Casing material
Ductile I
Ductile I
Ductile I Ductile I Ductile I Ductile I
Ductile I
Ductile I
Ductile I
Ductile I
Ductile I
Casing Wall Thickness
.44
.44
.44
.44
.44
.44
.44
.44
.50
.50
.62
STUFF BOX DATA
(All Dimensions in Inches)
Packing
Bore
3.25 3.25 3.25 3.25 3.25 3.75 3.75 3.75 3.75 3.75 3.75
Dimensions
Depth 3.50
3.50
3.50
3.50
3.50
3.62
3.62
3.62
3.62
3.62
3.62
Sleeve O.D.
2.25
2.25
2.25
2.25
2.25
2.75
2.75
2.75
2.75
2.75
2.75
Packing Size/No. Rings W/O S. Cage
6.50
6.50
6.50
6.50
6.50
6.50
6.50
6.50
6.50
6.50
6.50
Packing Size/No. Rings W/ S. Cage
5.50
5.50
5.50
5.50
5.50
5.50
5.50
5.50
5.50
5.50
5.50
Seal Cage Width
.75
.75
.75
.75
.75
.94
.94
.94
.94
.94
.94
Mech. Seal
Bore
2.75
2.75
2.75
2.75
2.75
3.125
3.125
3.125
3.125
3.125
On Shaft
Depth
3.00
3.00
3.00
3.00
3.00
3.25
3.25
3.25
3.25
3.25
i Dimensions
Mech. Seal Size (Type 21 or 1)
1.75
1.75
1.75
1.75
1.75
2.000
2.000
2.000
2.000
2.000
Balanced Mech.
Major Dia.-->
1.88
1.88
1.88
1.88
1.88
2.12
2.12
2.12
2.12
2.12
l
{
Seal Size (Type 1B)
Minor Dia.-->
1.75
1.75
1.75
1.75
1.75
2.00
2.00
2.00
2.00
2.00
Mech. Seal
Bore
3.38
3.38
3.38
3.38
3.38
4.00
4.00
4.00
4.00
4.00
4.00
On Sleeves
Depth
3.00
3.00
3.00
3.00
3.00
3.12
3.12
3.12
3.12
3.12
3.12
Dimensions
Mech. Seal Size (Type 21 or 1)
2.25
2.25
2.25
2.25
2.25
2.75
2.75
2.75
2.75
2.75
2.75
Balanced Mech.
Major Dia.-->
2.38
2.38
2.38
2.38
2.38
2.88
2.88
2.88
2.88
2.88
2.88
l
{
Seal Size (Type 1B)
Minor Dia.-->
2.25
2.25
2.25
2.25
2.25
2.75
2.75
2.75
2.75
2.75
2.75
IMPELLER DESIGN DATA
(All Dimensions in Inches)
No. of Vanes
7
6
6
6
7
7
6
6
7
5
6
Inlet Area (Sq. Inches)
44.4
29.5
38.7
18.3
61.9
40.2
62.9
57.4
57.5
65.4
68.4
Inlet Velocity per 100 GPM (Ft/Sec)
.73
1.09
.83
1.75
.52
.90
.51
.54
.54
.49
.47
Maximum
Diameter
12.2 17.0 17.0 17.2 12.8 17.7 12.8 12.8 17.7 17.3 20.2
Minimum Diameter
7.0
10.0
10.0
13.0
8.0
10.0
8.0
8.5
10.0
12.0
12.0
Maximum Sphere
1.0
.47
.50
.70
1.13
.98
1.4
1.47
.97
1.16
.53
WR ^2 for Maximum Diameter (Lbs-Ft^2)
5.3
16.5
18.0
18.0
8.1
17.0
9.8
11.2
20.7
22.4
21.7
j Wear Ring Clearance – Diam. 175# & 280# W.P.
.010-.012 .010-.012 .010-.012 .010-.012 .010-.012 .010-.012 .010-.012 .010-.012 .010-.012 .010-.012 .010-.012
ej Wear Ring Clearance – Diam. 400# W.P.
.020-.024 .020-.024 .020-.024 .020-.024 .020-.024 .020-.024 .020-.024 .020-.024 .020-.024 .020-.024 .020-.024
SHAFT AND BEARING DATA
(All Dimensions in Inches)
Under
Sleeve
1.874 1.874 1.874 1.874 1.874 2.374 2.374 2.374 2.374 2.374 2.374
Under Mech. Seal on Shaft Type 21 or Type 1
1.750
1.750
1.750
1.750
1.750
2.000
2.000
2.000
2.000
2.000
Under Mech. Seal on Shaft Type 1B
1.875
1.875
1.875
1.875
1.875
2.125
2.125
2.125
2.125
2.125
At Coupling
1.375
1.375
1.375
1.375
1.375
1.625
1.625
1.625
1.625
1.625
1.625
Thru Impeller with Packing – Mech. Seal on Sleeve
1.937
1.937
1.937
1.937
1.937
2.437
2.437
2.437
2.437
2.437
2.437
k Thru Impeller with Mech. Seal on Shaft
1.939
1.939
1.939
1.939
1.939
2.439
2.439
2.439
2.439
2.439
Shaft Span
Bearing to Bearing Centerline
27.25
27.25
27.25
27.25
27.25
29.90
29.90
29.90
29.90
29.90
29.90
Inboard 6208
6208
6208
6208
6208
6309
6309
6309
6309
6309
6309
Ball Bearings
Outboard 5307
5307
5307
5307
5307
5308
5308
5308
5308
5308
5308
Packing
F20-D4 F20-D4 F20-D4 F20-D4 F20-D4 F20-E4 F20-E4 F20-E4 F20-E4 F20-E4 F20-E4
Mech. Seal on Shaft
F20-D5
F20-D5
F20-D5
F20-D5 F20-D5 F20-E5
F20-E5
F20-E5
F20-E5
F20-E5
F20-E5
Frame Designation
Mech. Seal on Shaft Sleeve
F20-D6
F20-D6
F20-D6
F20-D6 F20-D6 F20-E6
F20-E6
F20-E6
F20-E6
F20-E6
F20-E6
c With 250# FF flanges and 280# PSIG working pressure refer to pump as
M3x2x11S.
d With 250# FF flanges and 400# PSIG working pressure refer to pump as
H3x2x11S.
e For pumps with 400 PSI working pressure, wear ring clearances are doubled.
Derate pump efficiencies by 2 percentage points.
f Flange dimensions are in accordance with ANSI A21.10, AWWA C110 & ANSI
B16.1 class 125.
g Flange dimensions are in accordance with ANSI B16.1 class 250 except flanges
are flat faced, i.e. FF.
h The hydrostatic test will be accordance with the latest edition of the Hydraulic
Institute Standards, test will maintained for a minimum of 5 minutes.
i Type 1 and 21 seals have the same working lengths.
j For bronze impellers and casing rings. For diametral clearances for other
materials, consult factory.
l
Impeller is a light press fit on shaft, do not use construction with stainless steel
impellers.
K
Not available in mechanical seal on shaft arrangement.
