Page 43

FIGURE 39 – ASSEMBLY SECTION: PUMP WITH MECHANICAL SEALS ON SHAFT SLEEVES
DOWEL PIN LOCATION
AT PARTING LINE
SETTING DIMENSIONS
C. DISMANTLING (PUMP WITH MECHANICAL
SEALS ON SHAFT SLEEVES)
WARNING: Unexpected Startup Hazard
Disconnect and lockout power before
servicing. Failure to follow these instructions could
result in serious personal injury or death, or
property damage.
CAUTION: Extreme Temperature Hazard
Allow pump temperatures to reach
acceptable levels before proceeding. Open drain
valve. Do not proceed until liquid stops coming out
of drain valve. If liquid does not stop flowing from
drain valve, isolation valves are not sealing and
should be repaired before proceeding. After liquid
stops flowing from drain valve, leave drain valve
open and continue. Remove the drain plug located
on the bottom of the pump housing. Do not
reinstall plug or close drain valve until reassembly
is completed. Failure to follow these instructions
could result in property damage and/or moderate
personal injury.
(See exploded view on page 59.)
1. Drain the pump by opening vent plug (A,
Figure 40) and remove drain plugs (B and
C) on the suction and discharge nozzles.
TYPE 21
MECH
TYPE 1B
MECH
PUMP SIZE
TYPE 1
MECH. SEAL
(STANDARD)
SEAL SEAL
IMPELLER
LOCATION
DIMENSIONS
“A” “B” “A” “B” “A” “B”
“C”
3x2x11
6.62
6.75
6.00
6.12
7.00
7.12
8.755
6x4x9
9.312
6x4x10
7.56
7.75
6.94
7.12
8.06
8.25
10.625
6x4x11
7.56
7.75
6.94
7.12
8.06
8.25
10.625
6x4x12
6.62
6.75
6.00
6.12
7.00
7.12
9.755
6x4x14
6.62
6.75
6.00
6.12
7.00
7.12
9.755
6x6x9
9.312
8x6x9
6.62
6.75
6.00
6.12
7.00
7.12
9.755
8x6x10
10.625
8x6x12
6.62
6.75
6.00
6.12
7.00
7.12
9.755
8x6x12M
7.56
7.75
6.94
7.12
8.06
8.25
10.625
8x6x13
7.31
7.50
6.69
6.88
7.81
8.00
10.625
8x6x17
7.31
7.50
6.69
6.88
7.81
8.00
10.625
8x6x18
7.31
7.50
6.69
6.88
7.81
8.00
10.625
8x8x12
7.31
7.50
6.69
6.88
7.81
8.00
10.625
8x8x17
7.88
8.00
7.06
7.18
8.25
8.36
11.495
10x8x12
7.88
8.00
7.06
7.18
8.25
8.36
11.495
10x8x17
7.88
8.00
7.06
7.18
8.25
8.36
11.495
10x8x20
7.88
8.00
7.06
7.18
8.25
8.36
11.495
12x10x12
7.88
8.00
7.06
7.18
8.25
8.36
11.495
12x10x14
7.88
8.00
7.06
7.18
8.25
8.36
11.495
12x10x17
7.88
8.00
7.06
7.18
8.25
8.36
11.495
12x10x18
7.88
8.00
7.06
7.18
8.25
8.36
11.495
