Preliminary Datasheet
Single/Dual Low Bias Current, Low Voltage, Rail-to-Rail
Input/Output CMOS Operational Amplifiers
Jul. 2012 Rev. 1. 0 BCD Semiconductor Manufacturing Limited
19
AZV831/2
Typical Performance Characteristics (Continued)
V
IN
V
IN
50mV/div 50mV/div
V
OUT
V
OUT
50mV/div 50mV/div
Time (2 µs/div) Time (2µs/div)
Figure 40. Small Signal Pulse Response Figure 41. Small Signal Pulse Response
V
IN
V
IN
500mV/div 500mV/div
V
OUT
V
OUT
500mV/div 500mV/div
Time (10 µs/div) Time (10µs/div)
Figure 42. Large Signal Pulse Response Figure 43. Large Signal Pulse Response
C
L
=100pF, R
L
=100kΩ, A
V
=1 C
L
=100pF, R
L
=100kΩ, A
V
=1
C
L
=200pF, R
L
=100kΩ, A
V
=1 C
L
=200pF, R
L
=100kΩ, A
V
=1
V
CC
=3.0V
V
EE
=0V
V
CC
=5.0V
V
EE
=0V
V
CC
=1.6V
V
EE
=0V
V
CC
=1.8V
V
EE
=0V
