Functional block diagram, Absolute maximum ratings, Recommended operating conditions – Diodes AS324_A User Manual
Page 4: A product line of diodes incorporated
AS324/324A
Document number: DS36827 Rev.
2 - 2
4 of 14
January 2014
© Diodes Incorporated
AS324/324A
A Product Line of
Diodes Incorporated
Functional Block Diagram
Q2
Q4
Q3
Q1
Q8
Q9
6
A
4
A
Q10
Q11
50
A
Q5
Q6
Q13
Rsc
Cc
100
A
Q7
INPUTS
+
-
OUTPUT
Q12
V
CC
Absolute Maximum Ratings
(Note 1)
Symbol
Parameter
Rating
Unit
V
CC
Supply Voltage
40
V
V
ID
Differential Input Voltage
40
V
V
IN
Input Voltage
-0.3 to 40
V
P
D
Total Power Dissipation (T
A
= +25
o
C)
DIP-14
1130
mW
SOIC-14
800
TSSOP-14
710
T
J
Operating Junction Temperature
+150
C
T
STG
Storage Temperature Range
-65 to +150
C
T
LEAD
Lead Temperature (Soldering, 10 Seconds)
+260
C
Note 1:
Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating Conditions” is not implied.
Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol
Parameter
Min
Max
Unit
V
CC
Supply Voltage
3
36
V
T
A
Ambient Operating Temperature Range
-40
+85
C
