Package Outline Dimensions
(Cont. All dimensions in mm(inch).)
(3) Package Type: TSSOP-14
Note: Eject hole, oriented hole and mold mark is optional.
SEE DETAIL A
DETAIL A
0
8
TOP&BOTTOM
1.000(0.039) REF
4.300(0.169)
4.500(0.177)
6.200(0.244)
6.600(0.260)
4.860(0.191)
5.100(0.201)
0.340(0.013)
0.540(0.021)
INDEX
0.050(0.002)
0.150(0.006)
0.800(0.031)
1.050(0.041)
0.650(0.026)
0.190(0.007)
0.280(0.011)
0.250(0.010)
0.450(0.018)
0.750(0.030)
# 1 PIN
0.950(0.037)
1.050(0.041)
DEP
0
0.100(0.004)
0.090(0.004)
0.200(0.008)
R0.090(0.004)
R0.090(0.004)
0.200(0.008)
1.200(0.047) MAX
φ
>0
o
o
o
