AS324/324A
Document number: DS36827 Rev. 2 - 2
2 of 14
www.diodes.com
January 2014
© Diodes Incorporated
AS324/324A
A Product Line of
Diodes Incorporated
Typical Applications Circuit
AC
Line
SMPS
R2
Current
Sense
R7
R8
Battery
Pack
R4 R3
AZ431
R5
R1
Opto
Isolator
V
CC
GND
GND
1/4
AS324/A
+
-
1/4
AS324/A
R6
+
- V CC
Battery Charger
DC Summing Amplifier Power Amplifier
R6 100k
V
O
R5
100k
R1 100k
R2 100k
R3 100k
R4 100k
+V
1
+V
2
+V
3
+V
4
1/4 AS324/A
+
-
R1 910k
V
O
R2 100k
R3 91k
V
IN(+)
V
CC
R
L
1/4 AS324/A
-
+
