300mA RF ULDO REGULATOR AP2210
Data Sheet
9
Jan. 2012 Rev. 1. 6 BCD Semiconductor Manufacturing Limited
Parameter Symbol Conditions Min Typ Max Unit
Enable Input Logic-low Voltage V
IL
Regulator shutdown
0.4
V
0.18
Enable Input Logic-high Voltage V
IH
Regulator enabled 2.0 V
Enable Input Logic-low Current I
IL
V
IL
≤0.4V 0.01 1
µA
V
IL
≤0.18V 2
Enable Input Logic-high Current I
IH
V
IL
≥2.0V 5 20
µA
V
IL
≥2.0V 25
Note 2: Specifications in bold type are limited to -40 o C ≤T
J
≤125 o C. Limits over temperature are guaranteed by design, but not
tested in production.
Note 3: Output voltage temperature coefficient is defined as the worst case voltage change divided by the total temperature
range.
Note 4: Regulation is measured at constant junction temperature using low duty cycle pulse testing. Parts are tested for load
regulation in the load range from 0.1mA to 300mA. Changes in output voltage due to heating effects are covered by the thermal
regulation specification.
Note 5: Dropout voltage is defined as the input to output differential at which the output voltage drops 1% (T
J
=25 o C) or 2% (-
40
o
C ≤T
J
≤125 o
C) below its nominal value measured at 1V differential.
Note 6: Ground pin current is the regulator quiescent current plus pass transistor base current. The total current drawn from the
supply is the sum of the load current plus the ground pin current.
V
IN
=3.8V, I
OUT
=100 µA, C
IN
=1.0 µF, C
OUT
=2.2 µF, V
EN
≥2.0V, T
J
=25 o C, Bold typeface applies over -40 o C ≤T
J
≤125 o C (Note 2),
unless otherwise specified.
AP2210-2.8 Electrical Characteristics
Electrical Characteristics (Continued)
