300mA RF ULDO REGULATOR AP2210
Data Sheet
21
Jan. 2012 Rev. 1. 6
BCD Semiconductor Manufacturing Limited
Note 2: Specifications in bold type are limited to -40
o
C
≤T
J
≤125
o
C. Limits over temperature are guaranteed by design, but not
tested in production.
Note 3: Output voltage temperature coefficient is defined as the worst case voltage change divided by the total temperature
range.
Note 4: Regulation is measured at constant junction temperature using low duty cycle pulse testing. Parts are tested for load
regulation in the load range from 0.1mA to 300mA. Changes in output voltage due to heating effects are covered by the thermal
regulation specification.
Note 6: Ground pin current is the regulator quiescent current plus pass transistor base current. The total current drawn from the
supply is the sum of the load current plus the ground pin current.
Electrical Characteristics (Continued)
V
IN
=V
OUT
+1V, I
OUT
=100
µA, C
IN
=1.0
µF, C
OUT
=2.2
µF, V
EN
≥2.0V, T
J
=25
o
C, Bold typeface applies over -40
o
C
≤T
J
≤125
o
C
(Note 2), unless otherwise specified.
AP2210-ADJ Electrical Characteristics
