AP3105NA/NV/NL/NR
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(Note 1)
Symbol Parameter Rating Unit
V
CC
Power Supply Voltage 30 V
I
O
Gate Output Current 350 mA
V
FB
, V
SENSE
, V
CTRL
Input Voltage to FB, SENSE, CTRL -0.3 to 7 V
θ
JA
Thermal Resistance (Junction to Ambient) 250 °C/W
P
D
Power Dissipation at T
A
< +25°C 500 mW
T
J
Operating Junction Temperature -40 to +150 °C
T
STG
Storage Temperature Range +150 °C
–
ESD (Human Body Model) 3000 V
–
ESD (Machine Model) 300 V
Note 1: Stresses greater than those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress
ratings only, and functional operation of the device at these or any other conditions beyond those indicated under “Recommended Operating
Conditions” is not implied. Exposure to “Absolute Maximum Ratings” for extended periods may affect device reliability.
Recommended Operating Conditions
Symbol Parameter Min Max Unit
V
CC
Supply Voltage 10 25 V
