TLV271/TLV272
Electrical Characteristics
(cont.) (@T
A
= +25°C and V
DD
= 2.7V, 5V, ±5V unless otherwise specified.)
Output Characteristics
Parameter Conditions
T
A
Min Typ Max Unit
V
OH
High Level Output Voltage
V
IC
= V
DD
/2,
I
OH
= -1mA
V
DD
= 2.7V
+25°C 2.55
2.58
—
V
-40°C to +125°C
2.48
—
—
V
DD
= 5V
+25°C 4.9
4.93
—
-40°C to +125°C
4.85
—
—
V
DD
= ±5V
+25°C 4.92
4.96
—
-40°C to +125°C
4.9
—
—
V
IC
= V
DD
/2,
I
OH
= -5mA
V
DD
= 2.7V
+25°C 1.9
2.1
—
-40°C to +125°C
1.5
—
—
V
DD
= 5V
+25°C 4.6
4.68
—
-40°C to +125°C
4.5
—
—
V
DD
= ±5V
+25°C 4.7
4.84
—
-40°C to +125°C
4.65
—
—
V
OL
Low Level Output Voltage
V
IC
= V
DD
/2,
I
OL
= 1mA
V
DD
= 2.7V
+25°C —
0.1
0.15
V
-40°C to +125°C
—
—
0.22
V
DD
= 5V
+25°C —
0.05
0.1
-40°C to +125°C
—
—
0.15
V
DD
= ±5V
+25°C —
-4.95
-4.92
-40°C to +125°C
—
—
-4.9
V
IC
= V
DD
/2,
I
OL
= 5mA
V
DD
= 2.7V
+25°C —
0.5
0.7
-40°C to +125°C
—
—
1.1
V
DD
= 5V
+25°C —
0.28
0.4
-40°C to +125°C
—
—
0.5
V
DD
= ±5V
+25°C —
-4.84
-4.7
-40°C to +125°C
—
—
-4.65
I
O
Output Current
V
O
= 0.5V from rail,
V
DD
= 2.7V
Positive
rail +25°C — 4 —
mA
Negative rail
+25°C
— 5 —
V
O
= 0.5V from rail,
V
DD
= 5V
Positive
rail +25°C — 7 —
Negative rail
+25°C
— 8 —
V
O
= 0.5V from rail,
V
DD
= 10V
Positive
rail +25°C — 13 —
Negative rail
+25°C
— 12 —
Power Supply
Parameter Conditions
T
A
Min Typ Max Unit
I
DD
Supply Current (per op-amp)
V
O
= V
DD
/2
V
DD
= 2.7V
+25°C
— 470 560
µA
V
DD
= 5V
+25°C
— 550 660
V
DD
= 10V
+25°C —
625
800
-40°C to +125°C
—
—
1000
I
IB
Power Supply Rejection Ratio
(∆V
DD
/∆V
IO
)
V
DD
= 2.7V to 16V,
V
IC
= V
DD
/2, No load
+25°C 70
80
—
dB
-40°C to +125°C
65
— —
