TLV271/ TLV272

Document number: DS35394 Rev. 4 - 2

16 of 17

www.diodes.com

December 2013

© Diodes Incorporated

NEW PROD

UC

T

TLV271/TLV272

Suggested Pad Layout

Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.

SOT25

SO-8

MSOP-8

Dimensions Value (in mm)

Z

3.20

G

1.60

X

0.55

Y

0.80

C1

2.40

C2

0.95

Dimensions Value (in mm)

X

0.60

Y

1.55

C1

5.4

C2

1.27

Dimensions Value (in mm)

C

0.650

X

0.450

Y

1.350

Y1

5.300

X

Z

Y

C1

C2

C2

G

X

C1

C2

Y

X

C

Y

Y1
