BHS-Series Bi-Ocular Operator’s Manual 4—Technical Data
431-BHS0-00-10, Revision 110 29
4–7 Range Detection
Actual range may vary depending on camera set-up, environmental
conditions, and user experience.
QD35 FoV
13° Ч 10°
18° Ч 13°
Detect Man
(1.8 m × 0.5 m) 2,559’ (780 m) BHS-X Pro
3,740’ (1140 m) BHF-XR Pro
Recognize
Man 623’ (190 m) BHS-X Pro
919’ (280 m) BHF-XR Pro
Detect Vehicle
(2.3 m × 2.3 m) 7,054’ (2150 m) BHS-X Pro
8,366’ (2550 m) BHF-XR Pro
Recognize
Vehicle 1,837’ (560 m) BHS-X Pro
2,231’ (680 m) BHF-XR Pro
QD65 FoV
7° Ч 5°
10° Ч 8°
Detect Man
(1.8 m × 0.5 m) 4,757’ (1450 m) BHS-X Pro
6,234’ (1900 m) BHF-XR Pro
Recognize
Man 1,214’ (370 m) BHS-X Pro
1,608’ (490 m) BHF-XR Pro
Detect Vehicle
(2.3 m × 2.3 m) 2.42 miles (3900 m) BHS-X Pro
2.98 miles (4800 m) BHF-XR Pro
Recognize
Vehicle 3,412’ (1040 m) BHS-X Pro
4,429’ (1350 m) BHF-XR Pro
QD100 FoV
5° Ч 3°
6° Ч 4°
Detect Man
(1.8 m × 0.5 m)
6,808’ (2075 m) BHS-X Pro
8038’ (2450 m) BHF-XR Pro
Recognize
Man 1,772’ (540 m) BHS-X Pro
2,133’ (650 m) BHF-XR Pro
Detect Vehicle
(2.3 m × 2.3 m) 3.29 miles (5300 m) BHS-X Pro
3.73 miles (6000 m) BHF-XR Pro
Recognize
Vehicle 4,921’ (1500 m) BHS-X Pro
5,742’ (1750 m) BHF-XR Pro
