3—Operating Your Camera BHS-Series Bi-Ocular Operator’s Manual
20 March 2012
3–8 SD Card Door
The SD Card door is located on the bottom of the camera in front of
the battery compartment. The SD card, the USB connector, and the
Auto-Standby Enable switch is located under the door.
Note
To open the SD Card door, grasp
the two edges with your thumb and
finger and pull straight up.
Caution!
To close the SD Card door, slide the
lanyard strap back into the camera, position the door in place, and
then firmly press in the middle of the door until it is fully seated.
The Hot Shoe must be removed to access the SD Card door.
Do not stretch or break the rubber
lanyard that keeps the door captive
to the camera when opened.
mini-USB Auto-Standby Enable
switch
SD Card
Grasp SD card door edges and pull
