ASUS PRL-DLS motherboard user guide 2-27
Onboard LEDs
CPULED1 Lights if one or two CPU overheats or if CPU 1 is not inserted.
POWERLED1 Lights when the motherboard is turned ON.
STBYLED1 Lights when the motherboard receives standby power.
LED1-LED8 Port 80h post code LEDs (see next page)
2.9 Onboard LEDs
