1-6 Chapter 1: Product introduction
1.4 Motherboard overview
Before you install the PRL-DLS motherboard, familiarize yourself with its
physical configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.
1.4.1 Major components
The following are the major components of the PRL-DLS motherboard as
pointed out in the picture on page 1-7.
1. 604-pin CPU sockets
2. ServerWorks ® Grand Champion
SuperLite (GCSL) North Bridge
3. 8-pin 12V SSI power connector
24/20-pin ATX power connector
4. DIP switches
5. DDR DIMM sockets
6. Floppy disk connector
7. Serverworks CSB6 South Bridge
8. IDE connectors
9. 2 Ultra-160/320 SCSI Connectors
10. LSI-Logic ® SCSI-Controller
11. Flash ROM
12. DIP switches
13. ServerWorks ® PCI-PCI Bridge
14. ASUS ASIC
15. 4-pin IPMI connector
16. LPC Super-I/O controller
17. 80-pin ASMB daughterboard
connector
18. Serial port 2
19. ATI Rage-XL VGA controller
20. PCI-X slots (PCI-X1 to X4),
PCI 5 (PCI64), PCI6 (PCI32)
21. Intel ® 82540 Gigabit Ethernet
controller
22. Broadcom ® 5703CHK Ethernet
controller
23. PS/2 mouse port
24. Parallel port
25. RJ-45 ports
26. VGA port
27. Serial port 1
28. USB ports 1 and 2
29. Keyboard port
See page 1-8 for the specifications of each component. Refer to
Chapter 2 for detailed information on the components.
