ASUS K8N-E Deluxe motherboard 2-5
Internal Connectors Page
1. Floppy disk connector (34-1 pin FLOPPY) 2-20
2. Primary IDE connector (40-1 pin PRI_IDE) 2-21
3. Secondary IDE connector (40-1 pin SEC_IDE) 2-21
4. Serial ATA connectors (7-pin SATA1, SATA2) 2-22
5. RAID Serial ATA connectors (7-pin SATA_RAID1,
SATA_RAID2, SATA_RAID3, SATA_RAID4) 2-23
6. CPU fan connector (3-pin CPU_FAN) 2-24
7. Power fan connector (3-pin PWR_FAN) 2-24
8. Chassis fan connector (3-pin CHA_FAN) 2-24
9. Serial Port 2 connector (10-1 pin COM2) 2-24
10. ATX power connector (20-pin ATXPWR) 2-25
11. ATA 12V power connector (4-pin ATX12V) 2-25
12. USB headers (10-1 pin USB56, USB78) 2-26
13. CD connector (4-pin CD) 2-27
14. AUX connector (4-pin AUX) 2-27
15. IEEE 1394 connector (10-1 pin IE1394_1) 2-27
16. Front panel audio connector (10-1 pin FP_AUDIO) 2-28
17. GAME/MIDI connector (16-1 pin GAME) 2-28
18. Chassis intrusion connector (4-1 pin CHASSIS) 2-29
19. System panel connector (20-pin PANEL) 2-29
- System power LED (Green 3-pin PLED)
- System warning speaker (Orange 4-pin SPEAKER)
- Reset switch (Blue 2-pin RESET)
- ATX Power switch (Yellow 2-pin PWRSW)
- Hard disk activity LED (Red 2-pin IDE_LED)
