2-4 Chapter 2: Hardware information
2.2.4 Layout Contents
Slots Page
1. DDR DIMM slots 2-11
2. PCI slots 2-16
3. AGP slot 2-16
Jumpers Page
1. Clear RTC RAM (3-pin CLRTC) 2-17
2. USB device wake-up (3-pin USBPW12, USBPW34,
USBPW56, USBPW78) 2-18
Rear Panel Connectors Page
1. PS/2 mouse port 2-19
2. Parallel port 2-19
3. IEEE 1394 port 2-19
4. Gigabit LAN port (RJ-45) 2-19
5. Rear Speaker out port 2-19
6. Side Speaker out port 2-19
7. Line In jack 2-19
8. Line Out jack 2-19
9. Microphone jack 2-19
10. Center/Subwoofer port 2-20
11. USB 2.0 ports 3 and 4 2-20
12. USB 2.0 ports 1 and 2 2-20
13. Serial connector 2-20
14. S/PDIF optical cable jack 2-20
15. S/PDIF coaxial cable jack 2-20
16. PS/2 keyboard port 2-20
