2-36 ASUS Z87-C
2.7.4 CPU Q-Fan Control [Enabled]
Allows you to set the CPU Q-Fan operating mode.
Configuration options: [Disabled] [Enabled]
The following items appear only when you set the CPU Q-Fan Control to [Enabled].
CPU Fan Speed Low Limit [600 RPM]
Allows you to set the low limit warning for CPU Fan speed.
Configuration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]
CPU Fan Profile [Standard]
Allows you to set the appropriate performance level of the CPU fan.
[Standard]
Set to make the CPU fan adjust automatically depending on the CPU
temperature.
[Silent] Set to minimize the fan speed for quiet CPU fan operation.
[Turbo] Set to achieve maximum CPU fan speed.
[Manual] Set to assign the detailed fan speed control parameters.
The following items appear only when you set the CPU Fan Profile to [Manual].
CPU Upper Temperature [70]
Use the <+> or <-> keys to adjust the upper limit of the CPU temperature. The values
range from 20ºC to 75ºC.
CPU Fan Max. Duty Cycle(%) [100]
Use the <+> or <-> keys to adjust the maximum CPU fan duty cycle. The values range
from 20% to 100%. When the CPU temperature reaches the upper limit, the CPU fan
will operate at the maximum duty cycle.
CPU Lower Temperature [20]
Displays the lower limit of the CPU temperature.
CPU Fan Min. Duty Cycle(%) [20]
Use the <+> or <-> keys to adjust the minimum CPU fan duty cycle. The values range
from 0% to 100%. When the CPU temperature is under 40ºC, the CPU fan will operate
at the minimum duty cycle.
2.7.5 Chassis Q-Fan Control 1/3 [Enabled]
[Disabled] Disables the Chassis Q-Fan control feature.
[Enabled] Enables the Chassis Q-Fan control feature.
