2-20 ASUS Z87-C
Power Current Offset [Auto]
Allows you to increase or decrease the output current sensed by the CPU. It finds the
balance between optimal regulating while staying below the current threshold.
Configuration options: [Auto] [100%] [87.5%] [75.0%] [62.5%] [50.0%] [37.5%] [25.0%]
[12.5%] [0%] [-12.5%] [-25.0%] [-37.5%] [-50.0%] [-62.5%] [-75.0%] [-87.5%] [-100%]
Power Fast Ramp Response [Auto]
Allows you to increase to enhance the response of the voltage regulator during the
load transient.
Configuration options: [Auto] [0.00] - [1.50]
CPU Internal Power Saving Control
Power Saving Level 1 Threshold [Auto]
Lower value provides sufficient overclocking tolerance to enlarge the overclocking
potential. Higher value provides better power-saving condition.Use <+> or <-> key to
adjust the value. The values range from 0A to 80A at 1Amp increment.
Power Saving Level 2 Threshold [Auto]
Lower value provides sufficient overclocking tolerance to enlarge the overclocking
potential. Higher value provides better power-saving condition.Use <+> or <-> key to
adjust the value. The values range from 0A to 50A at 1Amp increment.
Power Saving Level 3 Threshold [Auto]
Lower value provides sufficient overclocking tolerance to enlarge the overclocking
potential. Higher value provides better power-saving condition.Use <+> or <-> key to
adjust the value. The values range from 0A to 30A at 1Amp increment.
2.5.15 Extreme OV [Disabled]
Disable this item to help protect the CPU from being burned by Over Voltage. When you
enable this item, you can choose a high level voltage to overclock, but will not guarantee the
CPU life.
Configuration options: [Enabled] [Disabled]
2.5.16 CPU Core Voltage [Auto]
Allows you to configure the voltage amount for the processor’s cores. Increase the voltage
when setting a high Core Frequency value.
Configuration options: [Auto] [Manual Mode] [Offset Mode]
The following item appears only when you set the CPU Core Voltage to [Manual].
CPU Core Voltage Override [Auto]
Allows you to set the CPU Core Voltage override. Use the <+> or <-> keys to adjust the
value, The values range from 0.001V to 1.920V with a 0.001V interval.
The following items appear only when you set the CPU Core Voltage to [Offset Mode].
