viii
Z87-C specifications summary
Rear Panel I/O Ports 1 x HDMI port
1 x D-Sub port
1 x DVI-D port
1 x LAN (RJ45) port
4 x USB 3.0/2.0 ports (blue)
2 x USB 2.0/1.1 ports
8-channel Audio I/O ports
Internal I/O
connectors
1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB ports
3 x USB 2.0/1.1 connectors support additional 6 USB ports
6 x SATA 6.0 Gb/s connectors (yellow)
1 x 4-pin CPU Fan connector supports both 3-pin (DC mode) and 4-pin
(PWM mode) CPU coolers control
1 x 4-pin CPU Optional Fan connector (CPU_OPT)
3 x 4-pin Chassis Fan connectors
1 x Front panel audio connector (AAFP)
1 x S/PDIF out header
1 x TPM connector
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
System Panel
1 x Clear CMOS jumper
1 x DirectKey button
1 x DirectKey (DRCT) connector
1 x COM port connector
BIOS features 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM BIOS 2.7,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS
3, My Favorites, Quick Note, Last Modified Log, F12 PrintScreen function,
F3 Shortcut functions, and ASUS DRAM SPD (Serial Presence Detect)
memory information
Manageability WfM 2.0, DMI 2.7, WOL by PME, PXE
Accessories 2 x Serial ATA 6.0Gb/s cables
ASUS I/O shield
User’s manual
Support DVD
contents
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
Form factor ATX form factor: 12 in. x 8.4 in. (30.5 cm x 21.4 cm)
Specifications are subject to change without notice.
