ix
P8H61-M EVO specifications summary
(continued on the next page)
CPU LGA1155 socket for Intel ® Second Generation Core™ i7 / Core™
i5 / Core™ i3 processors
Supports Enhanced Intel SpeedStep Technology (EIST)
Supports Intel ® Turbo Boost technology 2.0
* The Intel ® Turbo Boost technology 2.0 support depends on the
CPU types.
** Refer to www.asus.com for Intel ® CPU support list.
Chipset Intel ® H61 Express Chipset
Memory 4 x DIMMs, max. 16GB*, DDR3 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
Supports Intel ® Extreme Memory Profile (XMP)
* Refer to www.asus.com for the latest Memory QVL (Qualified
Vendors List).
** When you install a total memory of 4GB capacity or more,
Windows ® 32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows ® 32-bit operating system.
Graphics Support dual VGA output: HDMI and D-Sub, DVI and D-Sub, HDMI
and DVI
- Supports HDMI with max.resolution up to 1920 x 1200 @60Hz
- Supports single-link DVI with max. resolution up to 1920 x 1200
@60Hz
- Supports D-Sub with max. resolution up to 2048 x 1536 @75Hz
- Supports DirectX 10.1
- Supports Intel ® Quick Sync Video Technology
Expansion slots 2 x PCI Express 2.0 x16 slots (x16 / x1)
2 x PCI Express 2.0 x1 slots
Storage Intel ® H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors
Asmedia ® SATA controller:
- 2 x Serial ATA 6.0 Gb/s connectors
LAN Realtek ® 8111E Gigabit LAN controller
Audio Realtek ® ALC887 8-channel High Definition Audio CODEC
- Jack-Detection and Front Panel Jack-Retasking (HD only)
- Optical S/PDIF out ports at back I/O
USB 10 x USB 2.0/1.1 ports (6 ports at the mid-board, 4 ports at the back
panel)
4 x USB 3.0 ports (2 ports at the mid-board, 2 ports at the back
panel)
