2-22 ASUS P8H61-M EVO
Asmedia USB 3.0 Controller [Enabled]
[Enabled] Enables the onboard USB 3.0 controller.
[Disabled] Disables the controller.
PCIE Port Mode [Auto]
This item allows you to change the port control from Asmedia USB 3.0 controller (Front) to
PCIEx1 slot and vice-versa.
[Auto] PCIEx1_1 slot will change to Asmedia USB 3.0 controller
(Front) unless a device is detected in the PCIEx1_1 slot.
[Asmedia USB 3.0 controller] Enables the Asmedia USB 3.0 controller (Front). The
PCIEx1_1 slot is disabled.
[PCIEx1 Slot] Enables the PCIEx1_1 slot. The Asmedia USB 3.0 controller
(Front) is disabled.
Asmedia USB 3.0 Battery Charging Support [Disabled]
This item appears only when the Asmedia USB 3.0 Controller item is set to [Enabled].
[Enabled] Enables the Asmedia USB 3.0 battery charging function.
[Disabled] Disables this function
Serial Port Configuration
The sub-items in this menu allow you to set the serial port configuration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Configuration options: [Enabled] [Disabled]
Change Settings [IO=3F8h; IRQ=4]
Allows you to select the Serial Port base address. Configuration options: [IO=3F8h;
IRQ=4] [IO=2F8h; IRQ=3] [IO=3E8h; IRQ=4] [IO=2E8h; IRQ=3]
Parallel Port Configuration
The sub-items in this menu allow you to set the parallel port configuration.
Parallel Port [Enabled]
Allows you to enable or disable the parallel port (LPT).
Configuration options: [Enabled] [Disabled]
Change Settings [Auto]
Allows you to select an optimal setting for Super I/O devices. Configuration
options: [Auto] [IO=378h; IRQ=5;] [IO=378h; IRQ=5,6,7,9,10,11,12;] [IO=278h;
IRQ=5,6,7,9,10,11,12;] [IO=3BCh; IRQ=5,6,7,9,10,11,12;]
Device Mode [STD Printer Mode]
Allows you to change the printer port mode. Configuration options: [STD Printer Mode]
[SPP Mode] [EPP-1.9 and SPP Mode] [EPP-1.7 and SPP Mode] [ECP Mode] [ECP and
EPP 1.9 Mode] [ECP and EPP 1.7 Mode]
