P8H61-M EVO specifications summary
ASUS unique features 100% All High-quality Conductive Polymer Capacitors
ASUS TurboV
ASUS MemOK!
GPU Boost
ASUS Anti-Surge Protection
ASUS EPU
ASUS EFI BIOS
ASUS AI Suite II
ASUS AI Charger
ASUS Fan Xpert
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
ASUS exclusive
overclocking features
SFS (Stepless Frequency Selection):
- Internal Base Clock tuning from 80MHz up to 300MHz at
1MHz increment
Overclocking protection:
- ASUS C.P.R. (CPU Parameter Recall)
Rear panel ports 1 x PS/2 keyboard / mouse combo port
1 x Optical S/PDIF out port
1 x HDMI port
1 x DVI port
1 x D-Sub port
1 x LAN (RJ-45) port
2 x USB 3.0 ports
4 x USB 2.0/1.1 ports
8-channel audio I/O ports
Internal connectors/
switches/ buttons
3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1
ports
1 x USB 3.0 connectors support additional 2 USB 3.0 ports
2 x SATA 6.0 Gb/s connectors
4 x SATA 3.0 Gb/s connectors
1 x CPU fan connector
2 x Chassis fan connectors
1 x Front panel audio connector
1 x S/PDIF Out connector
1 x System panel connector
1 x COM connector
1 x LPT connector
1 x TPM connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
1 x GPU Boost switch
1 x MemOK! button
BIOS features 32 Mb Flash ROM, EFI BIOS, PnP, DMI v2.0, WfM 2.0,
ACPI v2.0a, SM BIOS v2.6, Multi-language BIOS
(continued on the next page)
