• Do not forget to connect the 4-pin EATX12V power plug; otherwise, the

system will not boot.

• Use of a PSU with a higher power output is recommended when

configuring a system with more power-consuming devices. The system

may become unstable or may not boot up if the power is inadequate.

• If you are uncertain about the minimum power supply requirement for your

system, refer to the Recommended Power Supply Wattage Calculator

at http://support.asus.com/PowerSupplyCalculator/PSCalculator.

aspx?SLanguage=en-us for details.

PSU suggested list

ACBEL POLYTECH INC PC7057-Z6AG 390W W/PFC
ACBEL POLYTECH INC PC7009-000G 380W W/PFC

8. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V)

These connectors are for ATX power supply plugs. The power supply plugs

are designed to fit these connectors in only one orientation. Find the proper

orientation and push down firmly until the connectors completely fit.

2-28

Chapter 2: Hardware information
