ASUS P5N-VM WS 4-25
Entering the NVIDIA ® MediaShield BIOS RAID utility
To enter the NVIDIA ® MediaShield BIOS RAID utility
1. Boot up your computer.
2. During POST, press to display the main menu of the utility.
The RAID BIOS setup screens shown in this section are for reference only, and
may not exactly match the items on your screen.
At the bottom of the screen are the navigation keys. These keys allow you to move
through and select menu options.
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [↑↓] Select [ENTER] Popup
MediaShield BIOS Apr 25 2008
- Define a New Array -
RAID Mode: Mirrored Striping Block: Optimal
Free Disks Array Disks
Port Disk Model Capacity Port Disk Model Capacity
0.0. ST3160812AS 149.04GB
0.2. ST3160812AS 149.04GB
0.1. ST3160812AS 149.04GB
[←] Del
