2.2.2

Layout contents

Internal connectors

Page

1.

ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)

2-28

2.

LGA775 CPU Socket

2-6

3.

CPU and chassis fan connectors (4-pin CPU_FAN, 4-pin

CHA_FAN1-2, 3-pin CHA_FAN3-4)

2-26

4.

DDR2 DIMM slots

2-11

5.

NVIDIA Quadro FX470 Serial ATA connectors

(7-pin SATA1-4 [red]; 7-pin SATA5-6 [black])

2-23

6.

Chassis intrusion connector (4-1 pin CHASSIS)

2-27

7.

System panel connector (20-8 pin PANEL)

2-29

8.

Onboard LED (SB_PWR)

2-1

9.

TPM connector (20-1 pin TPM)

2-25

10.

Clear RTC RAM (3-pin CLRTC)

2-20

11.

USB connectors (10-1 pin USB78, USB910, USB1112)

2-24

12.

Front panel audio connector (10-1 pin AAFP)

2-27

13.

Optical drive audio connector (4-pin CD)

2-25

ASUS P5N-VM WS

2-3
