1 overview – Asus P5QL-E User Manual
Page 35
ASUS P5QL-E
2-11
Channel
Sockets
Channel A
DIMM_A1 and DIMM_A2
Channel B
DIMM_B1 and DIMM_B2
2.4
System memory
2.4.1
Overview
The motherboard comes with four Double Data Rate 2 (DDR2) Dual Inline Memory
Modules (DIMM) sockets.
The figure illustrates the location of the DDR2 DIMM sockets:
P5QL-E
P5QL-E
240-pin DDR2 DIMM Sockets
