xii
P5QL-E specifications summary
CPU LGA775 socket for Intel ® Core™2 Extreme /
Core™2 Quad / Core™2 Duo / Pentium ® Extreme /
Pentium ® D / Pentium ® 4 Processors
Supports Intel ® next-generation 45nm multi-core CPUs
Compatible with Intel ® 06/05B/05A processors
* Refer to www.asus.com for Intel CPU support list
Chipset Intel ® P43 / ICH10R with Intel ® Fast Memory Access
Technology
System Bus 1600 (overclocking) / 1333 / 1066 / 800 MHz
Memory Dual-channel memory architecture
- 4 x 240-pin DIMM sockets support non-ECC,
unbuffered DDR2 1066 / 800 / 667 MHz memory
modules
- Supports up to 16 GB system memory
* Refer to www.asus.com or this user manual for the
Memory QVL (Qualified Vendors Lists).
Expansion Slots 1 x PCIe x16 slot
2 x PCIe x1 slots
3 x PCI
Storage Southbridge
- 6 x SATA 3.0 Gb/s ports
- Intel ® Matrix Storage Technology supports RAID 0,
1, 5, and 10
PCIe Storage Controller
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 1 x eSATA
LAN Atheros L1E PCIe Gigabit LAN controller featuring
AI NET 2
High Definition Audio Realtek ® ALC1200, 8-channel High Definition Audio CODEC
- Supports Jack-Sensing, Multi-streaming and Front
Panel Jack-Retasking
- Coaxial S/PDIF Out ports at back I/O
- Optical S/PDIF Out ports at back I/O
- ASUS Noise Filter
IEEE 1394 LSI-FW3227 controller supports 2 x IEEE 1394a
ports (one at midboard; one at back panel)
USB 12 x USB 2.0 ports (6 ports at midboard, 6 ports at back
panel)
(continued on the next page)
