Page 28
2-4
Chapter 2: Hardware information
2.2.4
Layout contents
Slots/Connectors/Jumpers
Page
1.
PCI slots
2-19
2.
PCI Express x1 slots
2-19
3.
PCI Express 2.0 x16 slot
2-19
4.
Clear RTC RAM (3-pin CLRTC)
2-20
5.
CPU / Northbridge overvoltage setting (3-pin
OV_CPU, 3-pin OV_NB)
2-21
6.
USB device wake-up (3-pin USBPW1-4, PS2_USBPW56,
USBPW7-10, USBPW1112
2-22
7.
Floppy disk drive connector (34-1 pin FLOPPY)
2-24
8.
IDE connector (40-1 pin PRI_EIDE)
2-25
9.
ICH10R Serial ATA connectors (7-pin SATA1-6)
2-26
10.
USB connectors (10-1 pin USB 78, USB 910, USB 1112)
2-27
11.
IEEE 1394a port connector (10-1 pin IE1394_2)
2-28
12.
CPU, chassis, and power fan connectors (4-pin CPU_FAN, 3-pin
CHA_FAN1-2, 3-pin PWR_FAN)
2-29
13.
Optical drive audio connector (4-pin CD)
2-29
14.
Chassis intrusion connector (4-1 pin CHASSIS)
2-30
15.
Digital audio connector (4-1 pin SPDIF_OUT for ASUS HDMI
VGA card)
2-30
16.
Front panel audio connector (10-1 pin AAFP)
2-31
17.
Serial port connector (10-1 pin COM1)
2-31
18.
ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
2-32
19.
System panel connector (20-8 pin PANEL)
2-33
20.
ASUS Q-Connector (system panel
2-34
