ASUS Blitz Extreme 4-31
4.6.6 Hardware Monitor
CPU Temperature; MB Temperature; NB Temperature
SB Temperature; OPT Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU,
motherboard, northbridge, southbridge and the assigned device temperatures.
Select [Ignored] if you do not wish to display the detected temperatures.
North Bridge Overheat Protection [Auto]
Allows you to enable/disable the northbridge overheat auto-protection function or
set the temperature over which the system shuts down.
Configuration options: [Auto] [70C] [80C] [Disabled]
South Bridge Sensor Select [SB Overheat Protection]
Allows you to switch the target the temperature sensor aims at between the
southbridge and any device with a thermal sensor cable connected to the
OPT_TEMP2 connector.
Configuration options: [SB Overheat Protection] [OPT_TEMP2]
Remove the thermal sensor cable from the assigned device when you set this
item to [SB Overheat Protection].
The next item varies depending on whether you set the South Bridge Sensor
Select item to [SB Overheat Protection] or [OPT_TEMP2].
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Hardware Monitor
CPU Temperature [30.5ºC/86.5ºF]
MB Temperature [35ºC/95ºF]
NB Temperature [34ºC/94ºF]
SB Temperature [42ºC/107.5ºF]
OPT Temperature [N/A]
North Bridge Overheat Protecti[Auto]
South Bridge Sensor Select [SB Overheat Protec]
South Bridge Overheat Protecti[Auto]
OPT_TEMP1 Overheat Protection [Disabled]
CPU Fan and Chassis Fan
OPT Fan and Power Fan
VCORE Voltage [ 1.280V]
FSB Termination Voltage [ 1.232V]
North Bridge Voltage [ 1.280V]
DRAM Voltage [ 1.584V]
CPU Temperature
BIOS SETUP UTILITY
Power
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
Scroll down to see more items.
v02.58 (C)Copyright 1985-2006, American Megatrends, Inc.
Select Screen
Select Item
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
DRAM Reference Voltage [ 1.584V]
South Bridge Voltage [ 1.072V]
PLL Voltage [ 1.520V]
3.3V Voltage [ 3.200V]
5V Voltage [ 5.040V]
12V Voltage [12.152V]
