4 of 6

Q-TECH Corporation - 10150 W. Jefferson Boulevard, Culver City 90232 - Tel: 310-836-7900 - Fax: 310-836-2157 - www.q-tech.com

LOW PHASE NOISE, SPACE LEVEL OCXO

3.3 to 15Vdc - 1MHz to 125MHz

Q-TECH

CORPORATION

QPDS-0008 (Revision B, April 2013 ) (ECO# 10835)

Environmental Specifications

Q-Tech Standard Screening similar to (MIL-PRF-55310) is available. Q-Tech can also customize screening and test procedures to meet

your specific requirements. The packages are designed and processed to exceed the following test conditions:

Environmental Test

Test Conditions

Initial Accuracy at Reference Temperature

MIL-PRF-55310, Type 4, Class 3

Frequency Warm-up

MIL-PRF-55310, Type 4, Class 3

Initial Frequency-Temperature Accuracy

MIL-PRF-55310 (4.8.10.1)

Frequency-Voltage Tolerance

MIL-PRF-55310

Frequency-Load Tolerance

MIL-PRF-55310

Phase Noise Steady-State

MIL-PRF-55310

Phase Noise Random Vibration

MIL-PRF-55310

Output Power (Sinusoidal Waveform)

MIL-PRF-55310

Output Logic Voltage Levels (Square wave )

MIL-PRF-55310

Rise Time and Fall Time (Square wave )

MIL-PRF-55310

Duty Cycle (Square wave )

MIL-PRF-55310

Harmonic and Sub-harmonic Distortion

MIL-PRF-55310

Spurious Response

MIL-PRF-55310

Oven Input Current-Power

MIL-PRF-55310, Type 4, Class 3

Temperature Cycling

MIL-STD-883, Method 1010, Cond. B

Constant Acceleration

MIL-STD-883, Method 2001, Cond. A, Y1

Seal Fine Leak

MIL-STD-883, Method 1014, Cond. A & C

Burn-in

240 hours, At highest operating temperature with load

Aging

30 days, MIL-PRF-55310, Type 4, Class 3

Random Vibration

MIL-STD-883, Method 2026

Shock, Non Operating

MIL-STD-883, Method 2002

Thermal Shock, Non Operating

MIL-STD-202, Method 107, Cond. B

Ambient Pressure

MIL-STD-202, 105, Cond. G, 5 minutes dwell time minimum

Resistance to Solder Heat

MIL-STD-202, Method 210, Cond. C

Terminal Strength

MIL-STD-202, Method 211, Cond. C

Resistance to Solvents

MIL-STD-202, Method 215

Solderability

MIL-STD-202, Method 208

ESD Classification

MIL-STD-883, Method 3015, Class 1HBM 0 to 1,999V

Non-destructive Bond Pull

MIL-STD-883, Method 2023

Please contact Q-Tech for higher shock requirements
