LOW PHASE NOISE, SPACE LEVEL OCXO
3.3 to 15Vdc - 1MHz to 125MHz
Q-TECH
CORPORATION
QPDS-0008 (Revision B, April 2013 ) (ECO# 10835)
Parameters Conditions Requirements
Output Frequency Range (Fo) 1MHz — 125MHz
Supply Voltage (Vdd) ±5.0% +3.3Vdc, +5Vdc, +12Vdc and +15Vdc
Initial Tolerance @+25ºC ±0.2ppm
Temperature Range See Option Codes
Frequency Stability vs. Temperature See Option Codes
Frequency Stability vs. Voltage Variation Over Temperature Range ±10PPB
Frequency Stability vs. Load Variation ±5.0% Load Variation ±20PPB
Warm-up Power max. @-40ºC 4.8W
Steady State Power max. @+25ºC 2.7W
Warm-up Time @+25ºC to ±100PPB (2 hours ref.) 10 min.
Output Waveform Sine Wave HCMOS
Output Power (See note 1) +3.0±1.0dBm
Output Power Stability (See note 2) Over Temperature Range ±1.0dBm
Duty Cycle Over Temperature Range 50%±5.0%
Output Load 50Ω 10kΩ//15pF
Harmonics Over Temperature Range -35dBc
Spurious (See note 3) Over Temperature Range -90dBc
Aging
Per Day 1PPB
15 years 1.5PPM
G-Sensitivity max. 1PPB/G
Phase Noise for 50MHz OCXO (typ.)
1Hz -70dBc/Hz
10Hz -102dBc/Hz
100Hz -132dBc/Hz
1kHz -148dBc/Hz
10kHz -155dBc/Hz
100kHz -155dBc/Hz
• Phase Noise and Jitter built to specification
including static and vibration.
• Low supply current
• QCI tests
• Tight frequency stability versus temperature,
supply voltage, and load variations
• Low spurious (see note 3)
• Low frequency aging, Allan Variance
• High-shock resistant
Notes:
1. The output level is determined by the supply
voltage, load, and package size.
2. Typical amplitude stability over temperature is
±10% or less.
3. Typical spurious level is better than -100dBc over
the spectrum of 100kHz to 1GHz.
Other Design and Test Options
Electrical Characteristics
