SCANTECH ID (Champtek company) ORION O-3050 - Manual (Page 5)

Table of contents
Preface ...................................................................................................i
Chapter 1 The ORION O-3050 ..................................................................... 1
1.1 Unpacking the ORION O-3050 ................................................ 2
1.2 Declaration of conformity ...................................................... 4
1.3 Scanning bar codes with the ORION O-3050 ........................... 5
1.4 Scanner labelling .................................................................. 6
1.5 Maintaining the scanner......................................................... 9
1.6 Controlling the scanner from the POS system ....................... 10
Chapter 2 Installing the ORION O-3050 ...................................................... 13
2.1 Connecting the scanner....................................................... 14
2.2 Interface selection .............................................................. 16
2.3 Installing the scanner on a counter surface ........................... 17
2.4 Installing the scanner with the counter stand ............................ 19
2.5 Installing the scanner using the flexible scanner stand............ 19
2.6 Removing the scanner from the back cover plate .................. 22
Appendices ............................................................................................... 23
A Connector types and pin definitions ...................................... 24
B Technical specifications....................................................... 27
C Troubleshooting.................................................................. 29
