Appendices 24
A CONNECTOR TYPES AND PIN DEFINITIONS
The ORION supports triple interface in one standard unit: RS232, Keyboard
Wedge (KBW) and USB/USB plus power. The various pin definitions for the
applicable Data port are given on page 20 and 21. The connector to be
used for the port is indicated below.
To activate USB or KBW interface, follow this sequence:
1. Plug in the appropriate interface cable and then power up the
scanner.
2. Scan the following codes from the Configuration Guide:
- Open the scanner Programming Mode by scanning code 1.1
- Return to factory default settings by scanning code 1.3
Pin definitions for multi interface: Connector: RJ-48, 10 pins
Multiple Interface
RS-232 KBW USB Powered USB
Pin Description Description Description Description Remark
1 - - IFID IFID IFID = Interface ID
2 CTS PC-Clock - - -
3 RxD PC-Data - - -
4 TxD KB-Data - - IFID = Interface ID
5 RTS KB-Clock - - -
6 Ground Ground Ground Ground Ground
7
- PC - 5V PC - 5V - -
8 - - - +12V
Direct Power,
may be used to
power scanner
9 -
IFID: connect
to ‘6’
D + D +
IFID = Interface ID
D + = USB data
10 - - D - D - D - = USB data
