Billet Specialties Premium Tru Trac Serpentine System - Big Block Ford - Manual (Page 7)

www.billetspecialties.com
Figure 2: Prepare & Install Timing Cover
(A) Install oil pan end seal into timing cover with a thin bead of RTV silicone (use sparingly).
Lubricate crank seal with motor oil or grease to protect seal at start-up. Apply Permatex
Hylomar® gasket dressing to both sides of timing cover gasket and place on engine block.
Install Timing Cover
(B) Slide timing cover over studs. Apply anti-seize to four 5/16-18 x 2” ARP 12pt. cap screws.
Install 5/16” stainless steel washers to each screw at this time. Thread screws and washers
into bottom mount holes in timing cover and finger tighten.
For Kits With Power Steering
Apply anti-seize to two 3/8-16 x 1” socket head cap
screws. Place power steering bracket #14607 to timing
cover and thread the two 3/8-16 x 1” socket head screws
through bracket and into timing cover. Tighten firmly.
7
(B)
(A)
Install timing pointer in the factory location.
