9
- Security/Access control system
- General data acquisition application
- Truck/Bus monitoring system
- Car diagnostics
Please note that this manual assumes that the user has some knowledge of Bluetooth and TCP/IP
Internetworking protocols and terminologies.
1.2. Package Check List
- DC Power Adapter
- Quick Start Guide
- RS232 Serial Console Cable
- Ethernet Cross Cable
- Dipole antenna
1.3. Product Specification
Parani-MSP1000
Dual 10/100 Base-T Ethernet with RJ45 connector Ethernet interface
Supports Static IP and Dynamic IP address
Bluetooth v2.0 + EDR
Class 1
Level: 17dBm
Frequency: 2.4GHz
Profiles - Serial Port, LAN access over PPP, PAN, Dial up Networking
Bluetooth interface
Working distance:
DAT-G01R Antenna - Stub(Dafault) Antenna up to 150m
DAT-G01R Antenna - DAT-G01R Antenna up to 200m
DAT-G01R Antenna - DAT5-G01R Antenna up to 300m
DAT-G01R Antenna - PAT-G01R Antenna up to 500m
DAT5-G01R Antenna- DAT5-G01R Antenna up to 400m
DAT5-G01R Antenna- PAT-G01R Antenna up to 600m
PAT-G01R Antenna - PAT-G01R Antenna up to 1000m
Point to multi point
connectivity MSP1000A : Up to 7 Bluetooth connections
MSP1000B : Up to 14 Bluetooth connections
MSP1000C : Up to 28 Bluetooth connections
Network protocols IPv4, ICMP, ARP, TCP, HTTP, Telnet, TFTP,
SSH, https, SSL, TLS, DNS,
SCP, Syslog, NTP
Configuration Web, Telnet, SSH, Serial Console
Diagnostic LED Power, Status, Ethernet0, Ethernet1
Signal Strength, No of Connections
Power Supply voltage: 5V DC
Nominal Current Consumption: 1.2A@ 5VDC approximately
