30
4.2.3. Station mode
The Station transfers data from Repeater to outside. A Bluetooth module of Station can be connected
from seven Repeaters. But Repeater-to-Repeater connection is not allowed.
4.3. AP service
The Parani-MSP1000 supports the Personal Area Network profile, Dial-up Network profile and LAN
access over PPP profile. Bluetooth devices that supports PAN, DUN and LAP have the ability to
access the LAN through the Parani-MSP1000.
Figure 4-4 Bluetooth AP Service
4.3.1. Private address
The Parani-MSP1000 uses private addresses for PAN, DUN and LAP connections. When using PAN,
the Parani-MSP1000 assigns IP address via DHCP, and when using DUN and LAP, the Parani-
MSP1000 assigns IP address via Internet Protocol Control Protocol (IPCP). Available private
addresses are as follows:
 10.0.0.0 ~ 10.255.255.255
Table 4-1 Reserved Addresses in 10.x.x.x
10.0.0.1 Reserved for Parani-MSP1000
10.0.0.50 ~ 10.0.0.99 Reserved for PAN connections
10.0.0.100 ~ 10.0.0.200 Reserved for LAP & DUN connections
 172.16.0.0 ~ 172.16.255.255
Table 4-2 Reserved Addresses in 172.16.x.x
172.16.0.1 Reserved for Parani-MSP1000
