SENA Parani-MSP1000 User Manual
Page 15
15
[root@MSP1000 /]# editconf
-------------------------------------------------------------------------------
Welcome to MSP1000 configuration page
Current Time
: 7/14/2007 12:22:56
Serial No.
: msp1000-test1234
F/W Rev.
: v1.0.0
MAC Addr.(eth0) : 00:01:95:AF:BF:DD
IP Mode (eth0) : Static
IP Addr.(eth0)
: 192.168.161.5
-------------------------------------------------------------------------------
1. Network configuration
2. System administration
3. System status & log
4. CF card configuration
5. Monitoring
6. Save changes
7. Exit without saving
8. Exit and apply changes
9. Exit and reboot
--> 1
8)
Select menu 1. [Network Configuration] and then proceed to [Ethernet 0] configuration to set
up the IP address of the box. Users may set up the network configuration according to their
environment. Once network set-up is done, users may access the box through telnet/ssh
connection or via a web browser.
-------------------------------------------------------------------------------
Network Configuration
-------------------------------------------------------------------------------
1. ETHERNET 0 (eth0) configuration
2. ETHERNET 1 (eth1) configuration
3. Firewall configuration
4. TCP configuration
--> 1
-------------------------------------------------------------------------------
ETHERNET 0 (eth0) configuration
-------------------------------------------------------------------------------
1. IP mode: Static IP
2. IP address: 192.168.14.123
3. Subnetmask: 255.255.0.0
4. Gateway: 192.168.1.1
5. Primary DNS: 168.126.63.1
6. Secondary DNS: 168.126.63.2
-->
From the main menu screen, the users may select a menu item for configuration of the Parani-
MSP1000 parameters by selecting the menu number and pressing the [ENTER] key. In the submenu
screen, users can configure the required parameters guided by online comments.
NOTE: Be sure to perform “save” and “apply” command before you exit from editconf menu program.
All the parameters can be stored into the non-volatile memory space of the box, but the settings will
not be stored until users perform “save” command on the menu. All the configuration change will be
effective after entering “apply” command.
