2)
Connect the other end of the cable to the serial port of user’s computer.
3)
Run a terminal emulator program such as HyperTerminal. Set up the serial configuration
parameters of the terminal emulation program as follows:
9600 Baud rate, Data bits 8, Parity None, Stop bits 1, Hardware flow control (RTS/CTS)
4)
Press [ENTER] key.
5)
Type the user name and password to log into the HelloDevice Pro Series.
A factory default
setting of the user name and password are both admin.
login : admin
Password : *****
6)
If the user logged into the HelloDevice Pro Series successfully, the main menu screen will
appear on the computer.
From the main menu screen, shown below in Figure 2-8, users can select the menu item for the
configuration of the HelloDevice Pro Series parameters by typing the menu number and pressing
[ENTER] key. In the submenu screen, users can configure the required parameters guided by online
comments. All the parameters are stored into the non-volatile memory space of the HelloDevice Pro
Series, and it will not be stored until users select menu 7.Save changes. When users are finished
with the configuration, the system needs to be rebooted by selecting the menu 9.Exit and reboot.
All the configuration changes will be effective after the reboot.
-------------------------------------------------------------------------------
Welcome to PS-400 configuration page
Current time: 2002/05/04 14:13:25
Serial No.
: PS200-020200028
MAC Address: 00-01-95-04-13-80
F/W REV.
: V1.2.12
UP time
: 0 Days 02:26:00
IP mode
: DHCP
IP Address : 192.168.0.152
-------------------------------------------------------------------------------
Console#1 (Serial) : Connected
Console#2 (Telnet) : Available (NULL)
Console#3 (Telnet) : Available (NULL)
Console#4 (Telnet) : Available (NULL)
-------------------------------------------------------------------------------
Select menu
1. IP Configuration
2. Serial port configuration
3. System Status & log
4. System administration
5. Advanced options
6. System tools
7. Save changes
8. Exit without reboot
9. Exit and reboot
----->
Figure 2-8. The main menu screen (PS400)
