Replacing the deuterium bulb for dh-2000-bal model – Ocean Optics DH-2000 User Manual
Page 26
A: Maintenance
18
000-10000-025-02-1209
Replacing the Halogen Bulb for All Models Except
DH-2000-BAL
►
Procedure
1. Open the six slotted screws (14) and open the casing cover.
2. Remove the screw (21) with the tool (20) provided with the spare bulb (19).
3. Disconnect the old Halogen bulb from the connection plugs (18)
4. Open the screws of the cable-clamp on the lamp-side and remove the defective Halogen lamp
module.
5. Insert the new Halogen lamp module and Replace the screw (21).
