1: Setup

000-10000-025-02-1209

Unpacking the DH-2000

►

Procedure

1. Unpack your lamp assembly and power supply carefully. Although the lamp is rigidly mounted,

dropping this instrument can cause permanent damage.

2. Inspect the outside of the instrument and make sure that there is no damage. Do not use the

instrument if damage is present.

3. Use this instrument in a clean laboratory environment (see

Contents

Your DH-2000 package should contain the following:



DH-2000 unit



Power cord



One IC-DB15-2 interface cable for shutter operation (DH-2000-S, DH-2000-BAL, DH-2000-
FHS, and DH-2000-S-DUV-TTL models only)



UV safety goggles

Connecting the Cables

►

Procedure

1. Connect the power cord to an outlet and to the rear of the unit.

2. If you have a DH-2000-S, DH-2000-BAL, DH-2000-FHS, or DH-2000-S-DUV-TTL connect the

15-pin interface cable for external control of TTL lamp shuttering.

3. Connect the fiber optic cable (see

Connecting the Fiber Optic Cable

Use the following procedure to connect the cable to the lamp.
