2: DH-2000 Specifications
8 000-10000-025-02-1209
Specifications
Specifications Deuterium Lamp Criteria
Tungsten-Halogen Lamp
Criteria
Wavelength Range 210–400 nm 300–1500 nm
Current – Voltage – Stability 0,01 % / h 0.4% of voltage
Current – Voltage – Drift 0,01 % / h
Warm-Up Time 20 minutes 40 minutes
Lamp Voltage
Lamp Current
Ignition 580V / 20°
Operating 85 V / 0.3A
12V DC / 1.67A
Lamp Lifetime 1000 hours
Radiation Characteristics
Aperture 0.5mm NA26°
(13°) Focused
PIN Position at SUB-D 15 Pin Connector
(Only -S / -FHS / -BAL models)
(Only -TTL model)
Shutter PIN 13: TTL / PIN 10: Ground
PIN 2 Deuterium / PIN3 Halogen / PIN 4 Ground
Possible Filter Dimensions (only -FHS
model)
Up to diameter or square 25mm x 4mm, or 20mm x 6mm
Performance Guaranteed Temperature 5°C – 35°C
Humidity 5 - 95% without condensation at 40°
Internal Power Consumption 25 W 20 W
Total Power
Max. Power Consumption
100 Watt/190 Watt (Heating D-Lamp for 20 seconds)
Power Requirements:
European Version (prior to 4/2003)
USA Version (prior to 4/2003)
All units manufactured after 4/2003
230-240V 50/60 Hz
110-115V 50/60 Hz
90-240V 50/60 Hz
See Operating Environment for specific information.
Markings / Directives CE; VDI/VDE 0160; EN 61010
Weight Approximately 6 kg
Size 150 x 135 x 319 mm
