SIDACtor ® Protection Thyristors
167
Revised: February 22, 2011
© 2011 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Baseband Protection (Voice-DS1)
Capacitance Values
Part Number
pF
Pin 1-2, 3-2
Tip-Ground, Ring-Ground
pF
Pin 1-3
Tip-Ring
MIN MAX MIN MAX
P0602ACLxx 25 250 10 145
P1402ACLxx 55 155 30 90
P1602ACLxx 45 145 25 85
P2202ACLxx 45 115 25 65
P2702ACLxx 40 105 20 60
P3002ACLxx 35 95 20 55
P3602ACLxx 35 90 15 50
P4202ACLxx 30 85 15 50
P4802ACLxx 30 85 15 50
P6002ACLxx 30 80 15 45
Part Number Marking
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
V
DRM
@l
DRM
=5μA
V
S
@100V/μs
V
T
@I
T
=2.2 A
I
H
I
S
I
T
Capacitance
V min V max V min V max V max
mA
min
mA
max
A
max
Pins 1-2, 3-2 Pins 1-3 Pins 1-2, 3-2
P0602ABLxx P0602AB 25 40 50 80 4 50 800 2.2
See
Capacitance
Values Table
P1402ABLxx P1402AB 58 77 116 154 4 150 800 2.2
P1602ABLxx P1602AB 65 95 130 190 4 150 800 2.2
P2202ABLxx P2202AB 90 130 180 260 4 150 800 2.2
P2702ABLxx P2702AB 120 160 240 320 4 150 800 2.2
P3002ABLxx P3002AB 140 180 280 360 4 150 800 2.2
P3602ABLxx P3602AB 170 220 340 440 4 150 800 2.2
P4202ABLxx P4202AB 190 250 380 500 4 150 800 2.2
P4802ABLxx P4802AB 220 300 440 600 4 150 800 2.2
P6002ABLxx P6002AB 275 350 550 700 4 150 800 2.2
P0602ACLxx P0602AC 25 40 50 80 4 50 800 2.2
P1402ACLxx P1402AC 58 77 116 154 4 150 800 2.2
P1602ACLxx P1602AC 65 95 130 190 4 150 800 2.2
P2202ACLxx P2202AC 90 130 180 260 4 150 800 2.2
P2702ACLxx P2702AC 120 160 240 320 4 150 800 2.2
P3002ACLxx P3002AC 140 180 280 360 4 150 800 2.2
P3602ACLxx P3602AC 170 220 340 440 4 150 800 2.2
P4202ACLxx P4202AC 190 250 380 500 4 150 800 2.2
P4802ACLxx P4802AC 220 300 440 600 4 150 800 2.2
P6002ACLxx P6002AC 275 350 550 700 4 150 800 2.2
Part Number
pF
Pin 1-2, 3-2
Tip-Ground, Ring-Ground
pF
Pin 1-3
Tip-Ring
MIN MAX MIN MAX
P0602AALxx 15 145 10 90
P1402AALxx 40 60 20 35
P1602AALxx 35 60 20 35
P2202AALxx 30 50 15 30
P2702AALxx 25 45 15 25
P3002AALxx 25 40 15 25
P3602AALxx 25 35 10 20
P4202AALxx 25 35 10 20
P4802AALxx 20 35 10 20
P6002AALxx 20 35 10 20
P0602ABLxx 15 250 10 145
P1402ABLxx 40 155 20 90
P1602ABLxx 35 145 20 85
P2202ABLxx 30 115 15 65
P2702ABLxx 25 105 15 60
P3002ABLxx 25 95 15 55
P3602ABLxx 25 90 10 50
P4202ABLxx 25 85 10 50
P4802ABLxx 20 85 10 50
P6002ABLxx 20 80 10 45
Note: Off-state capacitance (C
O
) is measured at 1 MHz with a 2 V bias.
Notes:
- Absolute maximum ratings measured at T
A
= 25ºC (unless otherwise noted).
- Devices are bi-directional (unless otherwise noted).
- XX Part Number Suffix: ‘RP’ (Reel Pack), Blank (Bulk Pack), or ‘60’ (Type 60 lead form bulk pack)
Electrical Characteristics (continued)
