Littelfuse SP6002 Series - Manual (Page 5)

©2012 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to
www.littelfuse.com for current information.
TVS Diode Arrays
(SPA ® DJPEFT)
Revision: November 29, 2012
SP6002 Series
SP60
02
ESD and EMI Filter Devices - SP6002 Series
μDFN-16
JEDEC MO-229
Millimeters Inches
Min Max Min Max
A 0.45 0.55 0.018 0.022
A1 0.00 0.05 0.00 0.002
A3 0.102 REF 0.04 REF
b 0.15 0.25 0.006 0.010
D 3.20 3.40 0.126 0.134
D2 2.70 2.90 0.106 0.114
E 1.25 1.45 0.049 0.057
E2 0.30 0.50 0.012 0.020
e 0.40 BSC 0.016 BSC
L 0.15 0.35 0.006 0.014
16
1 2 3 4
0.10 C A B M
D
D2
b e
C0.2
1 2 3 4
0. 10 C
0. 05 C
E
L
E 2
A1 A A3
6 5
12 11 9 10
5 6
27Y
8 7
16 15 13 14
9
7 8
14 13 12 11 10 15
Side View
Top View
Bottom View
Pin 1 Marking
Pin 1
Locator
GND
PA D
Package Dimensions — μDFN-16
Embossed Carrier Tape & Reel Specification — μDFN-08
4.00±0.10
4.00±0.10 2.00±0.05
1.85±0.10
T
=0.20±0.03
3.
5
0±0.1
01
.7
5
±0.1
0
1.47±0.05
0.6
5
±0.0
5
A0 K0
B0
W
8.0
0±
0.30 0.1
0
ш1.00± 0.25
0.00
ш1.55± 0.01
0.00
22.1
2
ш1
3.22
ш1
79.90
ш1
55
.37
ш70.
55
ш1
5
.5
7
ш
5
8.1
1
24.32
1.46
1.
11
9.04
