©2012 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to

www.littelfuse.com

for current information.

TVS Diode Arrays

(SPA

®

DJPEFT)

Revision: November 29, 2012

SP6002 Series

SP60

02

ESD and EMI Filter Devices - SP6002 Series

Line Capacitance vs. DC Bias

0

10

20

30

40

50

DC Bias (V)

Capacitance (pF)

0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0

Time

T

emperature

T

P

T

L

T

S(max)

T

S(min)

25

t

P

t

L

t

S

time to peak temperature

Preheat

Preheat

Ramp-up

Ramp-up

Ramp-down

Ramp-do

Critical Zone
T

L

to T

P

Critical Zone
T

L

to T

P

Reflow Condition

Pb – Free assembly

Pre Heat

- Temperature Min (T

s(min)

)

150°C

- Temperature Max (T

s(max)

)

200°C

- Time (min to max) (t

s

)

60 – 180 secs

Average ramp up rate (Liquidus) Temp
(T

L

) to peak

3°C/second max

T

S(max)

to T

L

- Ramp-up Rate

3°C/second max

Reflow

- Temperature (T

L

) (Liquidus)

217°C

- Temperature (t

L

)

60 – 150 seconds

Peak Temperature (T

P

)

260

+0/-5

°C

Time within 5°C of actual peak
Temperature (t

p

)

20 – 40 seconds

Ramp-down Rate

6°C/second max

Time 25°C to peak Temperature (T

P

)

8 minutes Max.

Do not exceed

260°C

Soldering Parameters

Product Characteristics

Lead Plating

Pre-Plated Frame

Lead Material

Copper Alloy

Lead Coplanarity

0.0004 inches (0.102mm)

Substitute Material

Silicon

Body Material

Molded Epoxy

Flammability

UL 94 V-0

Notes :

1. All dimensions are in millimeters

2. Dimensions include solder plating.

3. Dimensions are exclusive of mold flash & metal burr.

4. Blo is facing up for mold and facing down for trim/form, i.e. reverse trim/form.

5. Package surface matte finish VDI 11-13.

Ordering Information

Part Number

Package

Size

Marking

Min. Order Qty.

SP6002-04UTG-1

μDFN-08

1.7x1.35mm

C12

3000

SP6002-06UTG-1

μDFN-12

2.5x1.35mm

C126

3000

SP6002-08UTG-1

μDFN-16

3.3x1.35mm

C128YYWW

3000

Part Numbering System

SP 6002

**

U T G -1

Series

Package

μDFN-08 (1.7x1.35mm)
μDFN-12 (2.5x1.35mm)
μDFN-16 (3.3x1.35mm)

T= Tape & Reel

G= Green

Number of Channels

04 = 4 Channel μDFN-08
06 = 6 Channel μDFN-12

TVS Diode Arrays
(SPA

®

%JPEFT)

08 = 8 Channel μDFN-16
