SIDACtor ® Protection Thyristors
Revised: 01/10/14
© 2014 Littelfuse, Inc.
Specifications are subject to change without notice.
Baseband Protection (Voice-DS1)
SIDACtor ® Series, DO-15
Package Symbol Parameter Value Unit
DO-15
T
J
Operating Junction Temperature Range -40 to +150 °C
T
S
Storage Temperature Range -65 to +150 °C
R
0JA
Thermal Resistance: Junction to Ambient 60 °C/W
Surge Ratings
Series
I
PP
I
TSM
10x560 1
10x560 2
10x1000 1
10x1000 2
5x310 1
10x700 2
50 / 60 Hz
Amps min Amps min Amps min Amps min
A 50 45 - 20
B 100 80 100 25
C - - 150 25
Thermal Considerations
Notes:
1 Current waveform in µs
2 Voltage waveform in µs
- Peak pulse current rating (I
PP
) is repetitive and guaranteed for the life of the product.
- I
PP
ratings applicable over temperature range of -40 to +85ºC
- The device must initially be in thermal equilibrium with -40°C < T
J
< +150°C
Time
Temper
at
ur
e
T
P
T
L
T
S(max)
T
S(min)
25
t
P
t
L
t
S
time to peak temperature
(t 25ºC to peak)
Ramp-down
Ramp-up
Preheat
Critical Zone
T L to T P
Figure 1
Soldering Parameters
Reflow Condition
Pb-Free assembly
(see Fig. 1)
Pre Heat
- Temperature Min (T
s(min)
) +150°C
- Temperature Max (T
s(max)
) +200°C
- Time (Min to Max) (t
s
) 60-180 secs.
Average ramp up rate (Liquidus Temp (T
L
)
to peak)
3°C/sec. Max.
T
S(max)
to T
L
- Ramp-up Rate 3°C/sec. Max.
Reflow
- Temperature (T
L
) (Liquidus) +217°C
- Temperature (t
L
) 60-150 secs.
Peak Temp (T
P
) +260(+0/-5)°C
Time within 5°C of actual Peak Temp (t
p
) 30 secs. Max.
Ramp-down Rate 6°C/sec. Max.
Time 25°C to Peak Temp (T
P
) 8 min. Max.
Do not exceed +260°C
