Littelfuse MC Balanced Series TO-220 - Manual (Page 2)

86
SIDACtor
® Protection Thyristors
© 2010 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Broadband Optimized ™ Protection
Balance MC
T
O-220 S
eries
Surge Ratings
S
eries
I
PP
I
TSM
50/60 Hz
di/dt
0.2x310 1
0.5x700 2
2x10 1
2x10 2
8x20 1
1.2x50 2
10x160 1
10x160 2
10x560 1
10x560 2
5x320 1
9x720 2
10x360 1
10x360 2
10x1000 1
10x1000 2
5x310 1
10x700 2
A min A min A min A min A min A min A min A min A min A min A/μs max
C 50 500 400 200 150 200 175 100 200 30 500
Package Symbol Parameter Value Unit
Modified
TO-220
PIN 1
PIN 2
PIN 3
T
J
Operating Junction Temperature Range -40 to +150 °C
T
S
Storage Temperature Range -65 to +150 °C
R
0JA
Thermal Resistance: Junction to Ambient 50 °C/W
Thermal Considerations
Capacitance Values
Part Number
pF
Pin 1-2 / 3-2
Tip-Ground, Ring-Ground
pF
Pin 1-3
Tip-Ring
MIN MAX MIN MAX
P1553ACMCLxx 30 55 20 35
P1803ACMCLxx 30 60 15 30
P2103ACMCLxx 30 45 15 30
P2353ACMCLxx 25 45 15 30
P2703ACMCLxx 25 40 15 30
P3203ACMCLxx 25 40 15 30
P3403ACMCLxx 20 35 15 25
P5103ACMCLxx 20 30 10 20
Note: Off-state capacitance (C
O
) is measured at 1 MHz with a 2 V bias.
Notes:
1 Current waveform in μs
2 Voltage waveform in μs
- Peak pulse current rating (I
PP
) is repetitive and guaranteed for the life of the product.
- I
PP
ratings applicable over temperature range of -40ºC to +85ºC
- The device must initially be in thermal equilibrium with -40°C < T
J
< +150°C
I
H
I
T
I
S
I
DRM
V
DRM V
T
+V -V
+I
-I
V
S
50
100
0
t
r
t
d
0
Peak
Value
Half Value
t – Time (μs)
I PP
– P
eak Pulse Current – %I
PP
t
r
= rise time to peak value
t
d
= decay time to half value
Waveform = t
r x t d
V-I Characteristics t
r
x t
d
Pulse Waveform
