Littelfuse MC Multiport Series MS-013 - Manual (Page 5)

SIDACtor ® Protection Thyristors
71
Revised: February 22, 2011
© 2011 Littelfuse, Inc.
Specifications are subject to change without notice.
Please refer to www.littelfuse.com for current information.
Broadband Optimized ™ Protection
Dimensions — MS-013
Package Type Description Quantity Added Suffix Industry Standard
U
Modified MS-013 6-pin
Tape and Reel Pack
1500 RP EIA-481-D
Modified MS-013 6-pin
Tube Pack
500 (50 per tube) TP N/A
Packing Options
Tape and Reel Specification — MS-013
7º TYP
E
D
A
B
Mold Split
Line
A
7º TYP
7º TYP
Pad Outline
0.065
(1.65)
0.460
(11.68)
0.138
(3.50) 0.059
(1.50)
C
A
F
7º TYP
G
J
H
Dimension are in inches
(and millimeters).
Burr Side
MIN Length
of Flat
4º
96º
Detail A K BSC*
Direction of Feed
0.700
(17.8)
.512 (13.0) Arbor
Hole Dia.
12.99
(330)
.630
(16.0)
Dimensions are in inches
(and millimeters)
.472
(12.0)
.157
(4.0)
Interior of the Tube
.045
(1.14)
.165
(4.19)
.150
(3.81)
90˚
.525
(13.34)
A
.225
(5.72)
Message Location
.310
(7.87) .108
(2.74) .005
20.000 ± .030
(508.00 ± 0.76)
.020 ± .005
(0.51 ± 0.13) WALL TYP.
.110
(2.79)
A
6
Dimensions are in inches
(and millimeters)
Tube Pack Dimensions — MS-013
Dimensions
Inches Millimeters
Min Max Min Max
A 0.360 0.364 9.14 9.25
B 0.352 0.356 8.94 9.04
C 0.400 0.412 10.16 10.46
D 0.043 0.045 1.09 1.13
E 0.047 0.055 1.19 1.40
F 0.293 0.297 7.44 7.54
G 0.289 0.293 7.34 7.44
H 0.089 0.093 2.26 2.36
J 0.041 0.049 1.04 1.24
K 0.020 0.51
BSC* 0.133 0.143 3.38 3.63
* BSC = Basic Spacing between Centers
